The CageKits FC RX7 Vert FD Spec Roll Cage Kit is engineered for exceptional precision and chassis fitment. Built from 1.5″ x .095″ 1020–1026 DOM tubing, each bar is CNC-notched, precision-bent, and laser-etched for perfect alignment and an accurate, straightforward install. Designed specifically for the FC RX7 Convertible (1988-1991), this kit delivers an exact fit within the chassis, providing a clean, professional foundation for your build — no custom fabrication required.

Made to Order — Ships Upon Completion

Door Bar Styles and Depth

This kit includes Ladder Door Bars and requires a gutted chassis for installation.

• Non-Gutted Door Bar Depth – Brings the bars closer to the interior to allow working windows. OEM door cards cannot be fully retained and must be trimmed halfway horizontally or replaced with a sheet metal panel.

Technical Details

• Built from 1.5″ x .095″ 1020–1026 DOM tubing
• CNC-notched joints for precise, tight fitment
• Laser-etched placement guides for easy tube identification and positioning
• Precision bent to match FC RX7 Vert chassis geometry
• Dual harness bar heights (choose configuration during install)
• Includes single or dual diagonal options for main hoop and rear down bars

Installation & Compliance Notes

• Compliance Responsibility: Customers are responsible for verifying that this roll cage meets the rules and technical requirements of their racing organization or sanctioning body.

• Cages are optimized for competition and off-street applications.

Want to see it in action? Check out our Instagram.
Need install help? Media tab’s got you.
